HB-25000-G: 25GigE camera with Gpixel GMAX0505

HB-25000-G: 26.21MP 25GigE camera with Gpixel GMAX0505

HB-25000-G features the Gpixel GMAX0505 CMOS sensor. Benefits include low noise, high dynamic range, and high frame rates. At full resolution (5120 x 5120), you get 75 frames per second. Its ultra high-speed 25GigE SFP28 interface offers many benefits including low-cost accessories, low CPU overhead, low latency, low jitter, and accurate multi-camera synchronization using IEEE1588. In addition, 25GigE SFP28 offers three supported cabling options for cable lengths from 1M to 10KM.

Benefits

High-speed 25GigE SFP28
25x the speed of GigE
GigE Vision® and GenICam™ compliant
Available in monochrome (HB-25000-G-M), and color (HB-25000-G-C)
Optional IP67 housing

Applications

Virtual Reality
Goal Line Technology
Volumetric Capture
Motion Capture
Immersive 3D Content
Finish Line Vision
Referee Assist

Sensor	GMAX0505
Resolution	5120 x 5120
Megapixels	26.21MP
Sensor Type	1.1” CMOS
Max Frame Rate	75fps
Cell Size	2.5×2.5µm
Standard Mount	C Mount
Shutter	Global
Bit Depth	8 & 10 bit
GPIO / Triggering	3 in, 3 out Software, External (Pulse or Edge)
Interface	25GigE SFP28
Exposure/Integration*	5µs-1s
Dynamic Range	>60dB @ 10bit
Monochrome Modes	Mono8, Mono10, Mono10Packed
Color Modes	RGB8, BGR8, YUV411, YUV422, YUV444
Raw Modes	BayerGB8, BayerGB10, BayerGB10Packed
Operating System	Win10 (64 bit), Linux (64 bit)
Compliance	CE, FCC, RoHS, WEEE, GigE Vision, GenICam
Power Requirements	9W, 12V
Operating Temperature	0C – 45C
Storage Temperature	-30C to +60C
Dimensions & Weight	97 x 66 x 52 – 500g
Warranty	2 Years

*all minimum exposure specs can vary from what is listed based on the limitations of each sensor as per notice from the manufacturer.
