White Paper: Benefits of 10GigE and 25GigE Cameras for Sports Technology Applications
INTRODUCTION
Technology in sports has been largely driven by business. A single missed call can easily amount to a loss of millions of dollars. Most owners and team members want to be on the winning side of a “call” but most accept technology as the most impartial and fair method for determining the outcome of a given play. Entertainment, however, has also been a big driving factor and an early influence.
A BRIEF HISTORY
Many consider the first major technology in sports to be the use of the photo-finish in racing applications. Horse racing first used film-based strip cameras in the 1930’s for such purposes and the adoption to other racing sports was steady.
Later, the use of radar for tracking ball speed in baseball in the 1960s. The same technology was much later adopted for tracking serve speed in tennis. These applications were driven more for entertainment value.
In the 1980s, a light-beam based computer system named Cyclops was first used in tennis as an electronic line judge against which even the likes of John McEnroe had few grounds for dispute. Not until the early 21st century did digital video cameras play a role in such efforts and this was a major game-changer which opened many doors in all areas of sports and its entertainment counterpart.
Using multiple cameras with tight synchronization, the pioneers in this realm used triangulation methods to virtually reconstruct the scene in full 3D. This later formed the basis for volumetric capture applications like Virtual, Mixed and Augmented reality- it seems that the line between sports and such applications is becoming quite gray. With such 3D content, there is very little left to the imagination and virtually no grounds for dispute.
Besides automated officiating, performance analysis has become a major application of such technology. Player tracking during matches as well as during training is greatly enhancing the product that is put on the field. During baseball practice, pitcher, batter, and ball movements can be fully captured in 3D and heavily analyzed to determine working formulas for on-field success even down to detecting the spin on a 90mph changeup with micro-second accuracy. On-field performance such as tracking position, player speed, shot speed, etc are now all a standard part of the game.
Lastly, as we have seen in some NBA and NFL broadcasts, some are applying the same technology for purely entertainment purposes such as allowing users to rotate fully around objects on the field for a semi-virtual reality experience. It is very much the same technology and the following paragraphs show why Emergent Vision Technologies Inc is the market leader in such spaces.
CHALLENGES
Largely, the challenges come down to the generation of accurate 3D content. They can require tight micro-second timing synchronization between image captures from multiple camera sources for optimal accuracy. They can require excellent image quality under a variety of lighting conditions. Some applications must have images which are high resolution while still maintaining an appropriate frame rate. They can have camera setups which span large areas including stadiums so the simplest options are preferred for system installation and maintenance. They can require many more cameras to complete a system for optimal accuracy. Lastly, as in most applications, cost can be an important factor.
HOW 10GIGE AND 25GIGE CAMERAS CAN ADDRESS THESE ISSUES
Timing Synchronization
Emergent 10GigE and 25GigE cameras provide a few options to tightly control the timing synchronization between cameras. Emergent has extensive experience in synchronizing cameras using a variety of methods including PTP, hardware triggering, etc, and have been able to demonstrate microsecond accuracies with minimal effort.
Image Quality
Emergent cameras only use the best sensors from top vendors such as Sony, Gpixel, and AMS and we work hard to squeeze every ounce of performance out of these sensors which leads to improvements in dynamic range which is important to sports applications in that systems often need to deal with varying lighting conditions.
Wide range of resolutions and frame rates
Sony sensors currently range from 0.5MP @ 1595fps to as high as 31MP @ 35fps and they are coming out very often with higher resolution and higher frame rate sensors. Gpixel sensors currently range from 5MP @ 290fps to 65MP @ 71fps and are on the rise. AMS has the 50MP @ 30fps.
The Sony IMX253 (12MP @ 80fps) and the Sony IMX255 (9MP @ 110fps) are currently the most popular for sports applications but higher resolution sensors like the Sony IMX342 (31MP @ 35fps), Gpixel GMAX0505 (25MP @ 75fps) and the AMS CMV50000 (50MP @ 30fps) are now getting some traction.
Emergent has just also released six new camera models utilizing Sony 4th generation sensors which range from 5MP up to 25MP with frame rates from 269fps to 98fps respectively. The associated sensors are: IMX530, IMX531, IMX532, IMX535, IMX536, IMX537. For highest speed, these sensors employ the highest speed SLVS-EC at 5GHz and Emergent is first to market with full support of these breakthrough sensors.
And, naturally, higher frame rate and resolution require a higher bandwidth interface to sustain this performance for limitless recording times and Emergent is also there with award winning bleeding edge 10GigE and 25GigE camera interface support.
SMPTE ST 2110 Compliance
Broadcast applications are making a switch to Ethernet based technologies to replace the aging, limited, and less cost effective SDI technologies. Having SMPTE ST 2110 compliance is an added benefit to drop cameras into new or existing infrastructures.
How 10GigE and 25GigE compare with other high-speed interfaces
Emergent 10GigE and 25GigE cameras, coupled with CSPI Myricom’s MVA or Mellanox’ VMA/Rivermax, equals or out-performs other interfaces in every technical category and its price performance is the best. With VMA/Rivermax or MVA, all the shortcomings associated with 1GigE w.r.t. CPU utilization, latency and jitter are obliterated. Industry acceptance is excellent as well.
Cabling Options
Here, the closest competitor is CXP. Low cost commodity SFP+ and SFP28 transceivers create a virtually limitless link length. In comparison, CXP6 and CXP12 will achieve 72m and 30m respectively but can go further with expensive fiber adapters. It is important to distinguish between SFP+/SFP28 transceivers and CXP or CameraLink fiber adapters. Transceivers are low cost commodity product which slots directly in the camera and NIC while the fiber adapters are expensive bulky external pieces of hardware (often the same size as the camera itself or even bigger) produced by very few suppliers and these sit somewhere in-between the camera CXP or CameraLink cable(s) and the fiber link which, interestingly enough, uses the same SFP+ transceivers that Emergent employs directly in the camera. And, naturally, you need one fiber adapter at each end of the link since the grabber will typically have the same interface as the camera.
Line Scan camera applications
As discussed in the introduction, film-based strip cameras have historically been employed for photo-finish racing applications. The equivalent camera in modern times is often a Line Scan camera such as the LR-8KG and LB-8KG by Emergent. The camera is placed with vertical orientation and is precisely and continuously scanning the finish line. Moving objects are scanned as they cross the finish line and static aspects of the scene remain unaltered.
Network Switches
Network switches play a bigger role in robust installations that some would think and the cost of such devices in multi-camera setups is considered low and dropping due to cross-industry use. There are three major reasons why switches may be employed:
PTP distribution
Here, a single high accuracy PTP grandmaster clock can be easily distributed to all devices which are connected through the switch.
Camera/Device Multiplexing
10x 10GigE cameras like the HR-12000-SC could be multiplexed onto a single 100GigE link back to a server holding a single-port 100GigE NIC. This is necessary for some systems which use servers with limited PCIe slots which hold the NICs. Consider that in a 10 camera per PC application that this would require 5x dual port 10GigE NICs which increases server cost due to higher slot count in addition to the added cost of the 5x Dual 10G NICs vs 1x Single 100G NIC. And note that a 100G NIC from Emergent will also come with the same performance advantages as stated above which is best in class.
Redundancy
With the multiplexing points in mind, consider that if a single server with a 100G NIC becomes unavailable that a quick switchover to a similar redundant server will allow for virtually 0 down time. Consider also that performing redundancy with fewer higher speed links like 1x 100G vs 10x 10G requires much fewer switch ports.
Cost Efficient
This is what it often all comes down to and we invite customers to get their complete system quotes from our competitors and absolutely make sure to perform the technical due diligence and then compare all results before committing to any solution. This goes as much for competitors pushing their expensive CXP wares as for competitors supplying 10GigE or other Ethernet based cameras as it is not just about the technology but it is also about the quality of the implementation and support. It is worth noting that most if not all 10GigE competing technology suffers performance issues that limit number of cameras per PC which has a significant impact on cost.
In conclusion, when getting quotes for comparison, make sure at minimum that 10GigE is being compared to either CXP6 x1/x2 or CXP12 x1 and that 25GigE is being compared to either CXP6 x4 or CXP12 x2.
Additionally, one should understand how many camera channels per PCIe slot you are getting in your frame grabber in comparison to our NICs. We offer 2x 25GigE port cards which is the equivalent of a CXP6 x8 card or CXP12 x4 assuming that the CXP card has independent camera channel support. Note also, as stated above, we offer support of a single 100G NIC which could replace 5x dual port 10G cards with multiplexing switches for large channel density improvements.
Lastly, understand your cabling options especially cable length restrictions as these can dictate a significantly added cost if CXP fiber converters are needed.
What is the overall benefit of using 10GigE and 25GigE cameras for my sports application
- Ultra high data/frame rates
- Many accessory and cabling options to cover any length
- Camera network support and accurate multi-camera synchronization methods including PTP support
- Multicast video technology
- Low CPU overhead, low latency, low jitter using Myricom’s MVA and Mellanox’ VMA
- Highest camera count per PC performance
- Very competitive cost/performance
- Industry acceptance due to IEEE and AIA standardization
Camera recommendations
Emergent Vision Technologies has numerous camera options for your sports application needs but the following have been work-horses for these applications:
HR-8000-S 10GigE Camera
8MP @ 110fps, SFP+ cabling with transceivers, Sony IMX255 Gen2 Sensor.
HR-12000-S 10GigE Camera
12MP @ 80fps, SFP+ cabling with transceivers, Sony IMX253 Gen2 Sensor.
HB-7000-S 25GigE Camera
7MP @ 210fps, SFP28 cabling with transceivers, Sony IMX420 Gen3 Sensor.
HB-25000-G 25GigE Camera
25MP @ 75fps, SFP28 cabling with transceivers, GPixel GMAX0505 Sensor.
HB-30000-S 25GigE Camera
30MP @ 35fps, SFP28 cabling with transceivers, Sony IMX342 Gen3 Sensor.
HB-50000 25GigE Camera
50MP @ 30fps, SFP28 cabling with transceivers, AMS CMV50000 Sensor.
In addition, the following recently released camera models promise to deliver excellent performance for all sports applications:
HB-5000-SB 25GigE Camera
5.1MP @ 269fps, SFP28 cabling with transceivers, Sony Pregius S IMX537 Gen4 Sensor.
HB-25000-SB 25GigE Camera
24.47MP @75fps, SFP28 cabling with transceivers, Sony Pregius S IMX530 Gen4 Sensor.
LR-8KG 10GigE Line-Scan Camera
8192 pixels horizontal, Single line- 137KHz- 8K, Trilinear- 45KHz- 8K, SFP+ cabling with transceivers, Gpixel GL0816 sensor
LB-8KG 25GigE Line-Scan Camera
8192 pixels horizontal, Single line- 200KHz- 8K, Trilinear- 66KHz- 8K, SFP28 cabling with transceivers, Gpixel GL0816 sensor
